Max Pressure: |
5,075 psi (350 bar) |
Temperature: |
-60°F to +350°F |
| |
|
|
|
(-51°C to +177°C) |
| |
Capacity: |
12 cu in – 13.5 gal (.20 – 51L) |
Inlet Ports: |
Threaded: FNPT, BSP |
| |
|
|
|
Flanged: ANSI |
| |
Materials: |
316L Stainless Steel |
|
|
| |
|
Carbon Steel |
|
|
| |
|
|
|
|
|
|
CAUTION: Stated max pressure is for ambient temperatures; max pressure not available on all models. Temperature ranges based on available materials. Consult BLACOH for specific ratings.
|
| |
|
| BLADDER OPTIONS |
ELASTOMERS |
TEMPERATURE LIMITS |
APPLICATIONS |
Buna |
+10°F to +180°F (-12°C to +82°C) |
Good flex life; use with petroleum, solvents and oil-based fluids. |
EPDM |
-60°F to +280°F (-51°C to +138°C) |
Use in extreme cold; good chemical resistance with ketones, caustics. |
Viton |
-10°F to +350°F (-23°C to +177°C) |
Use in hot and aggressive fluids; good with aromatics, solvents, acids and oils. |
PTFE |
+40°F to +220°F (+4°C to +104°C) |
Bellows design; excellent flex life; use with highly aggressive fluids. |
| |
|
|
|
|
|
|
|
